Name: 1500W Pure Sine Wave Inverter Charger
Brand: Suzhou Cosuper Energy Technology Co., Ltd.

Features of 1500W Pure Sine Wave Inverter Charger

Multi-functions: Battery inverter, AC charger, AC bypass and UPS
Three stage battery charging mode, compatible with Gel, AGM, Flooded, Lithium batteries
High efficiency gets the most out of your reserved energy
Built-in auto transfer switch between DC power and AC power
7 LED display show the working mode of the device
Reprogrammable Interactive Display Control System CR10 for easy data reading
Bypass mode increase the efficiency and make the quality of the AC output the same as AC input
Power Saving Mode helps preserve battery capacity over long period of no operation
Electronic protection against Over/under voltage, overload, over-current, overheating, short circuit
This kind of solar power inverter charger has 2 years warranty

Technical Specifications of 1500W Pure Sine Wave Inverter Charger

Models	LPT1500
Output Power	1500W
Surge Power	4500W
Output Voltage	100/110/120VAC±5%, 220/230/240VAC±3%
Oput Frequency	50/60Hz±0.5%
Output Waveform	True Sine Wave(THD<5%)
Power Factor	0.1~1
DC Input Voltage	12/24/48VDC
Voltage Range	10.0~16.0/20.0~31.0/42.0~62.0VDC
Power Saving Mode	<15W
Efficiency	110VAC 84%; 230VAC 84%
AC Charger
AC Input Voltage	90~135VAC/190~245VAC
DC Output Voltage	Fast(14.0~15.1V), Float(13.3V~13.8V), (2 for 24VDC, 4 for 48VDC)
Over Charge Protection	15.7VDC(2 for 24VDC, 4 for 48VDC)
Charge Current	110VAC 50A/25A/15A; 220VAC 45A/35A/20A
AC Bypass
Transfer Time	<8 ms
Input Volt. Waveform	Utility AC or Generator (Sine Wave)
Max Bypass Current	20A
Control&Signal
LED Indicator	Working Mode
LCD Screen	AC Input, AC Output, DC Input, Output Frequency, Load Percentage, Working Mode, Fault Indicator
Remote Control(optional)	CR10~11
Battery Type	Manual Optional
Safety&EMC
Safety	UL458, LVD (EN60950)
EMC	FCC Part15 Class A, CE (EN55022:2006+A1:2007)
Environment
Operating Temp	-20~50℃
Working Humidity	20~90%RH
Storage Temp	-30~70℃
Other Information
Cooling	Automatically controlled cooling fan
Weight(kg)	15
Size(mm)	425255185
Application	Vehicle, Yacht, Solar power systems, Portable equipment, Power tools, Home and office appliances
